WINKHAUS AV4-F Heritage 2070 Auto Locking Latch & Deadbolt 20mm Radius 1770mm Length 2 Hook – 45/92

The Heritage Autolock AV4 from Winkhaus is an automatic multi-point locking system which locks automatically when you pull the door closed and is designed for doors that need a traditional eye level cylinder pull locking point. This version adds improvements such as being non handed and a new hook design with increased operational tolerances. Two solid anti-push back hooks automatically engage when the door is closed and then a central magnetic trigger activates to lock, the locking points and the lock can be opened externally by a quarter of a turn of the key to the euro cylinder – available separately. The AV4 meets the requirements of PAS24 and is approved by the Police ‘Secured by Design’ security initiative. Please note that the Autolock AV4 can be upgraded to a motorised door locking system by using a blueMatic EAV4 motor or blueMatic EAV4+ motor, which allow the locked door to be opened from the inside as usual using the cylinder and unlocked from the outside using all potential-free access control systems.

• Heritage cylinder position where a traditional eye-level cylinder pull would be
• Non handed
• 92mm centres
• Can be upgraded with an electronic motor
• Latch and deadbolt
• 20mm radius faceplate
